Contact Lens Quick Reference and Fitting Guide: Vertex, LARS, RGP Patterns, Irregular Cornea and Scleral Lenses

Contact Lens Quick Reference and Fitting Guide: Vertex, LARS, RGP Patterns, Irregular Cornea and Scleral Lenses

Last updated: November 2026

Key points in 60 seconds

  • Convert spectacle to contact lens power above about ±4 D: Fc = F/(1 − dF), each meridian separately.
  • Toric rotation: LARS (left add, right subtract).
  • RGP patterns: alignment, steep (central pooling) and flat (central touch).
  • Irregular corneas need RGP or scleral lenses; teach every wearer the hygiene rules.
Clinic Desk ReferenceContact Lenses

Everyday contact lens fitting: converting spectacle power, toric lens rotation, rigid lens base curves, options for irregular corneas, and the safety advice every wearer needs.

Spectacle to contact lens power (vertex 12 mm)

Minus spectacleContact lensPlus spectacleContact lens
−4.00−3.75+4.00+4.25
−4.50−4.25+4.50+4.75
−5.00−4.75+5.00+5.25
−5.50−5.25+5.50+6.00
−6.00−5.50+6.00+6.50
−6.50−6.00+6.50+7.00
−7.00−6.50+7.00+7.75
−7.50−7.00+7.50+8.25
−8.00−7.25+8.00+8.75
−9.00−8.00+9.00+10.00
−10.00−9.00+10.00+11.25
−11.00−9.75+11.00+12.75
−12.00−10.50+12.00+14.00
−13.00−11.25+13.00+15.50
−14.00−12.00+14.00+16.75
−15.00−12.75+15.00+18.25
−16.00−13.50+16.00+19.75
−18.00−14.75+18.00+23.00
−20.00−16.25+20.00+26.25

Corneal-plane power = F ÷ (1 − dF), rounded to the nearest 0.25 D. Convert each principal meridian separately for astigmatic prescriptions, or use the transposition and vertex tool. Below ±4.00 D the difference is negligible.

Soft toric lenses: LARS

  • Look at the orientation mark on the eye. If the lens has rotated to the examiner's left, add the rotation to the prescribed axis; if to the right, subtract it (Left Add, Right Subtract).
  • Estimate the rotation from the mark spacing for that brand (often 10° or 15° between marks).
  • If rotation is unstable from blink to blink, change the lens design rather than the axis.
  • Spherical soft lenses usually cope with up to about 0.75 D of astigmatism; above that, consider toric lenses.

Rigid gas-permeable (RGP) lenses

  • For a spherical cornea, start on or slightly flatter than the flattest K; with corneal astigmatism, fit progressively steeper than flat K (about 0.25 D steeper for 1 D of cylinder, 0.50 D for 2 D; see the RGP calculator). Choose a total diameter of about 9.0–9.6 mm for regular corneas.
  • Tear lens rule (SAM-FAP): Steeper Add Minus, Flatter Add Plus; each 0.05 mm change in base curve ≈ 0.25 D.
  • Ideal fluorescein pattern: light central touch or alignment, mid-peripheral bearing, and a clear 0.4–0.6 mm edge band; the lens should move 1–2 mm on blinking.
  • RGP lenses correct corneal astigmatism through the tear lens; residual astigmatism comes from the crystalline lens.

Keratoconus and irregular corneas

LensBest forNotes
Small RGP / keratoconus designs (e.g. Rose K type)Mild to moderate conesAim for three-point touch; first choice in many clinics
Piggyback (RGP over soft)Poor RGP comfortHigher oxygen-permeable soft lenses only
Hybrid lensesCentred cones, comfort problemsRigid centre, soft skirt; costlier
Scleral lensesAdvanced cones, post-graft astigmatism, severe dry eyeVault the cornea; fill with preservative-free saline
Soft toric or custom softVery mild conesLimited vision quality in irregular corneas

From starting values to the lens you order

Calculators (including our contact lens calculator) give starting values for a trial lens, not a prescription. The sequence is always: choose a trial lens from the refraction and keratometry → let it settle (soft about 10–20 minutes, RGP 20–30 minutes) → assess fit (movement and centration; fluorescein for rigid lenses; rotation for torics) → over-refract → order → review the first lenses after a few days and again after a few weeks of wear.

Reading RGP fluorescein patterns

Instil fluorescein with a moistened strip, use the cobalt blue light with a yellow (Wratten) filter, and look after the lens has settled. Green means tear pooling (clearance); dark means touch (bearing).

PatternWhat you seeMeaning and what to change
Alignment (ideal)Even thin green layer centrally, light mid-peripheral bearing, a bright 0.4–0.6 mm edge band; 1–2 mm movement on blinkOrder as is
Apical clearance (steep)Central pool, sometimes bubbles, dark mid-peripheral ring of touch, little movementFlatten the base curve (FAP: add plus)
Apical touch (flat)Dark central bearing, wide green edge pooling, excessive movement, decentration (often high or low riding)Steepen the base curve (SAM: add minus) or enlarge the diameter
With-the-rule toric cornea on a spherical lensDark band of touch along the flat horizontal meridian with green pooling above and below ("dumbbell" or "H" pattern)Acceptable if centred and comfortable; if it rocks or decentres, try a slightly steeper base curve or a bitoric lens (usually above 2.50–3.00 D)
Too little edge liftThin or absent edge band, lens binds, 3 and 9 o'clock stainingIncrease edge lift or flatten peripheral curves
Too much edge liftVery wide bright edge band, edge awareness, bubbles under the edge, lens dropsReduce edge lift or steepen peripheral curves
Three-point touch (keratoconus)Light feathery touch on the cone apex with mid-peripheral bearing at two points and clear edgesThe usual target in a cone; heavy apical touch risks scarring; apical clearance designs are an alternative

Which lens for an irregular cornea?

In irregular corneas the shape on topography, not flat K, decides the lens family. Fit with trial lenses and fluorescein; calculations help only with power.

Corneal shape or conditionUsual first options
Mild keratoconus with a central (nipple) coneSoft toric or custom soft lens; corneal RGP if vision is poor
Mild to moderate keratoconusSmall-diameter keratoconus RGP designs (three-point touch); piggyback if comfort is poor
Inferior (oval or "sagging") cone, pellucid marginal degenerationLarger-diameter corneal RGP, hybrid, or scleral lens
Advanced keratoconus, globus cone, RGP intoleranceScleral lens; hybrid lens in selected cases
After myopic laser surgery (flat centre, oblate)Reverse-geometry corneal RGP or scleral lens
After keratoplasty (graft junction, high astigmatism)Scleral lens, large corneal RGP or hybrid; watch the graft endothelium
Severe ocular surface disease (SJS, GVHD, exposure)Scleral lens filled with preservative-free saline (also a therapeutic option)

Cone types: nipple (small, central or paracentral), oval (larger, inferior or inferotemporal) and globus (involving most of the cornea). As keratoconus advances the apex usually moves inferiorly. Cross-linking halts progression but does not remove the need for lenses. See keratoconus and topography and keratoconus screening.

Scleral lens basics

  • Names (Scleral Lens Education Society, 2013): corneal lenses rest entirely on the cornea; corneo-scleral lenses rest partly on the cornea and partly on the sclera; scleral lenses rest entirely on the sclera: mini-scleral up to 6 mm larger than the HVID, large scleral more than 6 mm larger.
  • Fitted by sagittal depth, not K. Two eyes with the same K can have very different sag; the normal eye has a sag of about 4,000 µm over a 15 mm chord. Choose a diagnostic lens by sag and adjust from the fit.
  • Central clearance: about 200–500 µm is generally considered adequate; lenses settle by about 100–150 µm over the first hours, so judge clearance after settling (optical section or AS-OCT).
  • Limbal clearance all round (360°), and a landing zone that sits on the conjunctiva without blanching vessels or impinging; check for compression rings on removal.
  • Indications: irregular corneas (keratoconus, post-graft, post-refractive, pellucid), and ocular surface disease (dry eye, Sjögren, SJS, ocular GVHD, neurotrophic and exposure keratopathy, limbal stem cell deficiency).
  • Handling: filled with preservative-free saline before insertion; mid-day fogging may need removal and refill. Corneal oedema can occur in compromised endothelium (low endothelial cell count, after keratoplasty): choose high-Dk materials and minimal clearance.

Common contact lens problems and fixes

ProblemCluesWhat to do
3 and 9 o'clock staining (RGP)Staining at the nasal and temporal cornea, with drynessImprove edge lift and lens position, encourage complete blinks, lubricants; consider larger diameter or a soft or scleral lens
Lens flexure (RGP)Residual astigmatism that changes with lens thickness; varying keratometry over the lensThicker or lower-flexibility material, steeper fit; flexure is common on toric corneas
Decentration (RGP)High-riding (lid attachment) or low-riding lensLow riding: larger, thinner or minus-carrier lens; high riding (lid attachment) is often acceptable; steepen if it is from a flat fit
Lens bindingRGP lens stuck on waking, ring indentationFlatten the fit, increase edge lift, avoid overnight wear
Tight soft lensLittle movement, conjunctival indentation, end-of-day rednessFlatter base curve, smaller diameter or a different material
Contact lens papillary conjunctivitis (CLPC/GPC)Itching, mucus, lens moving up; papillae on the upper tarsusStop or reduce wear, daily disposables, better cleaning; mast cell stabiliser or antihistamine drops
Superficial corneal neovascularisationVessels crossing the limbus by more than about 1 mmHigher-Dk lens (silicone hydrogel or RGP), fewer hours, no overnight wear
Red eye with infiltrates (CLARE, CLPU)Red eye on waking, small peripheral infiltrates, intact or small epithelial defectsStop lenses; always rule out microbial keratitis (central, large, painful or with discharge: scrape and treat)
Dryness and end-of-day discomfortSymptoms worse late in the day or with screensLubricants, shorter wear, daily disposable or different material, treat meibomian gland dysfunction
Pain, discharge or reduced visionAny wearerRemove lenses and see an eye doctor the same day: microbial keratitis until proved otherwise

For presbyopic patients see the multifocal and monovision tool in the contact lens calculator; for a lens that rotates, see the toric rotation tool.

Safety advice for every wearer: no sleeping in lenses unless prescribed; never use tap water, saliva or homemade solutions; no swimming or showering in lenses; replace cases monthly; remove lenses and seek help the same day for a painful red eye or blurred vision (risk of Pseudomonas and Acanthamoeba keratitis).

Related: contact lens clinic, contact lens care (for patients), topography and keratoconus card.

Key sources

  • Efron N. Contact Lens Practice. 4th ed. Elsevier; 2023
  • Phillips AJ, Speedwell L. Contact Lenses. 6th ed. Elsevier; 2018
  • Stapleton F et al. Risk factors for moderate and severe microbial keratitis in daily wear contact lens users. Ophthalmology 2012;119:1516–21
